Ultrasonic sensors XX, ultrasonic sensor t V dc pnp XXSID

• [Us] Rated Supply Voltage: 12...24 V DC reverse polarity protection
• Series Name: general purpose
• Type Of Output Signal: discrete
• Range Of Product: Telemecanique Ultrasonic sensors XX
• Detection System: diffuse
• Sensor Type: ultrasonic sensor
• Sensor Design: cylindrical M12
• Sensor Name: XXS
• Material: plastic
• Ip Degree Of Protection: IP67 conforming to IEC 60529

Contractual warranty

• Warranty: 18 months

Complementary

• Maximum Switching Current: 100 mA overload and short-circuit protection
• Maximum Delay First Up: 20 ms
• Maximum Voltage Drop: 1 V
• Supply Voltage Limits: 10-28 V DC
• Marking: CE

Offer Sustainability

• Circularity Profile: ENVEOLI111225EN
• Rohs Exemption Information: Yes
• Mercury Free: Yes
• Environmental Disclosure: ENVPEP111234EN
• Sustainable Offer Status: Green Premium product
• Eu Rohs Directive: Pro-active compliance (Product out of EU RoHS legal scope)
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• California Proposition 65: WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Environment

• Product Certifications: UL
• Ambient Air Temperature For Operation: -20-65 °C
• Resistance To Electromagnetic Fields: 10 V/m level 3 IEC 61000-4-3
• Ambient Air Temperature For Storage: -40-80 °C
• Standards: IEC 60947-5-2
• Resistance To Electrostatic Discharge: 8 kV level 4 IEC 61000-4-2
• Vibration Resistance: +/-1 mm 10-55 Hz)IEC 60068-2-6
• Shock Resistance: 30 gn in all 3 axes 11 ms IEC 60068-2-27
