Ultra Economy Edge-Lit Exit Sign 1-Face No Arrows Red Letters Clear Panel White

• Single-face, clear panel with red or green letters
• Modern edge-lit design
• Options with 90 minutes of emergency illumination
• Mounting options for wall/ceiling surface mount
• Select models compliant with California Title 20
• 5 Year Limited Warranty

• Input Wattage: 3.3W @120V and 277V
• Power Factor: ≥0.9
• Input Voltage:
• Operating Frequency (Hz): 60Hz
• Input Current @ 120V (mA): 30mA
• Input Current @ 277V (mA): 14mA
• Dual Voltage Circuit Operation: No
• Operating Temperature: 32°F to 122°F (0°C to 50°C)
• Battery Backup: AC Only
• Battery Operating Temperature: 32°C to 122°C (0°F to 50°F)
• Storage Temperature: 68°F to 86°F (20°C to 30°C)
• Self-Diagnostics: No, manual test only
• Remote Test Switch: No
• Listings: UL924 Listed, NFPA 101 (current Life Safety Code), NEC and OSHA illumination standards
• IP Rating: Suitable for indoor use in dry and damp environments

Spec Sheet
