Lutron Diva 3-Speed Fan Control and Light Switch, Single-Pole/3-Way, 1.5A Fan/1A LED, Clamshell Packaging

The Lutron Diva 3-Speed Fan Switch helps achieve the ideal comfort level for any home by controlling a single fan up to 1.5 Amps. The intuitive rocker switch turns the fan on/off to a preset and the linear slider adjusts between 3 speeds (Low, Medium and, High). Install with Lutron Claro Switches in 3-way applications. Coordinating Claro wall plates and 3-way switches sold separately. Available in 20+ colors to consistently match any Lutron device.

• Family/Collection: Diva
• Controls 1.5 A fan. Paddle turns on/off. Slide up to increase speed, down to decrease speed. 3 quiet fan speeds for increased comfort. For use with only one ceiling paddle fan. Does not include locator light. Designed to prevent motor hum.
• Includes (1) 3-speed fan switch; Gloss finish
• No Neutral Required; 120V
• Rated up to 1.5 Amp of indoor ceiling paddle fans
• One (1) Ceiling Paddle Fan Only Per Fan Control; Not Compatible With Fans With Proprietary Remotes Or Dc Motors
• 3-way compatible with existing switches
• Wire-lead connections
• Large paddle switch turns fan on and off to preset level and slider adjusts fan speed
• Provides 3 quiet fan speeds for comfort
• Fits large designer-style openings; Available in in 20+ colors
• Pairs perfectly with Lutron Claro wall plates for consistent color matching (sold separately)

• Actuator: Paddle switch
• Amperage Rating: 1.5
• Application: Fan Control
• Brand Name: Lutron
• Color: Almond
• Connection: Wire leads
• Contact Configuration: N-O
• Contact Rating: 1.5
• Mounting: Wallbox
• Number Of Poles: 1
• Size: 4.69 x 2.94
• Special Features: Controls 1.5 A fan. Paddle turns on/off. Slide up to increase speed, down to decrease speed. 3 quiet fan speeds for increased comfort. For use with only one ceiling paddle fan. Does not include locator light. Designed to prevent motor hum.
• Standard: UL, CSA, NOM
• Sub Brand: Diva
• Type: Fan control, 3-way/single-pole, clamshell packaging
• Voltage Rating: 120
• Wattage: 180
