Lutron phase adaptive power module dual voltage 3-wire fluorescent input, 120V

0

• When connected to a 20 A circuit breaker, provides capacity on a 3-wire fluorescent dimmer for a full 16 A load of lighting. May be used to dim incandescent, halogen, electronic low-voltage (ELV), magnetic low-voltage (MLV), neon/cold cathode, or Lutron Tu-Wire lighting sources. Phase adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers. Up to 3 power modules may be controlled by a single dimmer. Not for use with non-dim loads. Works with 120 VAC versions of Lutron 3-wire fluorescent dimmers, GRAFIK Eye QS and GRAFIK Eye 3000 Series control units. LP, LCP, and GP dimming panels, HomeWorks and Homeworks remote power panels, and EcoSystem interface C5-BMJ-xxx.
• Provides dimming control for 1 zone of a full 16A lighting load.
• May be used to dim incandescent, halogen, electronic low-voltage, magnetic low-voltage, neon/cold cathode.
• Phase-adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers.
• Up To 3 Power Modules May Be Controlled By A Single Dimmer (C5-Bmj- Will Control Only 1 Module).
• 3-wire fluorescent dimmer input
• Can be used in conjunction with BCI-0-10 for 0 - 10 V dimming applications. For more information, see Application Note #516 (Lutron P/N 048516) at www.lutron.com
• Models available for control voltage of 120V only or 220 - 277V.
• Models available for load voltage of 120V only or 120 - 277V.
• Compatible with 220 / 240V, non-CE systems. Contact Lutron for specific system applications.
• Not for use with non-dim loads.

• Application: Lighting Control
• Brand Name: Lutron
• Frequency Rating: 50 to 60
• Height: 5.1
• Input Voltage: 120
• Insulation: Plastic
• Length: 2.6
• Mounting: Surface or recess
• Output Voltage: 120 to 277
• Special Features: When connected to a 20 A circuit breaker, provides capacity on a 3-wire fluorescent dimmer for a full 16 A load of lighting. May be used to dim incandescent, halogen, electronic low-voltage (ELV), magnetic low-voltage (MLV), neon/cold cathode, or Lutron Tu-Wire lighting sources. Phase adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers. Up to 3 power modules may be controlled by a single dimmer. Not for use with non-dim loads. Works with 120 VAC versions of Lutron 3-wire fluorescent dimmers, GRAFIK Eye QS and GRAFIK Eye 3000 Series control units. LP, LCP, and GP dimming panels, HomeWorks and HomeWorks QS remote power panels, and EcoSystem interface C5-BMJ-xxx.
• Standard: UL, RoHS, CSA, NOM, CIDET
• Type: Power Module, phase-adaptive, with 3-wire fluorescent input
• Width: 6.3
