120-277V, 16A, Phase Adaptive Interface; Requires 220-277V panel or neutral-referenced wallbox control

Lutron Phase-adaptive power module provides dimming control for 1 zone of a full 16 A lighting load. May be used to dim incandescent, halogen, electronic low-voltage, magnetic low-voltage, and neon/cold cathode. Compatible with 2-wire fluorescent dimmer input.

• Provides dimming control for 1 zone of a full 16 A lighting load. May be used to dim incandescent, halogen, electronic low-voltage, magnetic low-voltage, neon/cold cathode. Phase adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers. Up to 3 power modules may be controlled by a single dimmer. Use for 2-wire fluorescent dimmer input. Compatible with 220/240 VAC, non-CE systems. Contact Lutron for specific system applications. Not for use with non-dim loads. Works with 120 VAC or 220-277 VAC versions of approved Lutron in-wall dimmers, GRAFIK Eye QS and GRAFIK Eye 3000 Series control units, LP, LCP, and GP dimming panels, HomeWorks and Homeworks remote power panels, and EcoSystem interface C5-BMJ-XXX.
• Provides dimming control for 1 zone of a full 16A lighting load.
• May be used to dim incandescent, halogen, electronic low-voltage, magnetic low-voltage, neon/cold cathode.
• Phase-adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers.
• Up To 3 Power Modules May Be Controlled By A Single Dimmer (C5-Bmj- Will Control Only 1 Module).
• 2-wire input
• Models available for control voltage of 120V only or 220 - 277V.
• Models available for load voltage of 120V only or 120 - 277V.
• Compatible with 220 / 240V, non-CE systems. Contact Lutron for specific system applications.
• Not for use with non-dim loads.

• Application: Lighting Control
• Brand Name: Lutron
• Frequency Rating: 50/60
• Input Voltage: 220-277
• Insulation: Plastic
• Mounting: Surface or recess
• Output Voltage: 120 to 277
• Special Features: Provides dimming control for 1 zone of a full 16 A lighting load. May be used to dim incandescent, halogen, electronic low-voltage, magnetic low-voltage, neon/cold cathode. Phase adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers. Up to 3 power modules may be controlled by a single dimmer. Use for 2-wire fluorescent dimmer input. Compatible with 220/240 VAC, non-CE systems. Contact Lutron for specific system applications. Not for use with non-dim loads. Works with 120 VAC or 220-277 VAC versions of approved Lutron in-wall dimmers, GRAFIK Eye QS and GRAFIK Eye 3000 Series control units, LP, LCP, and GP dimming panels, HomeWorks and HomeWorks QS remote power panels, and EcoSystem interface C5-BMJ-XXX.
• Standard: UL, RoHS
• Type: Power Module, phase-adaptive
