Multisound siren, Harmony XVS, prewired, white colour, 0...105dB, 43tones, 240V AC

• Range Of Product: Harmony XVS
• Product Or Component Type: multisound siren
• Device Short Name: XVS

Contractual warranty

• Warranty: 18 months

Complementary

• Height: 114 mm
• Color: White
• Mounting Support: bracket
• Electrical Connection: cable 6.5-8.5 mm, 0.33-0.33 mm² / AWG 22 signalling circuit) || cable 6.5-8.5 mm, 0.52-0.52 mm² / AWG 20 power circuit)
• Fixing Mode: 3 holes Ø 9 mm
• Material: PC (polycarbonate) back cover || PC (polycarbonate)/ABS (acrylonitrile butadiene-styrene) front || PC (polycarbonate)/ABS (acrylonitrile butadiene-styrene) back
• Marking: CE
• Width: 140 mm
• Depth: 223 mm
• Current Consumption: 50 mA 240 V
• Net Weight: 1.2 kg
• [Uimp] Rated Impulse Withstand Voltage: 4 kV

Offer Sustainability

• China Rohs Regulation: X
• Circularity Profile: ENVEOLI1411024EN
• Rohs Exemption Information: Yes
• Mercury Free: Yes
• Environmental Disclosure: ENVPEP1411024EN
• Eu Rohs Directive: Pro-active compliance (Product out of EU RoHS legal scope)
• California Proposition 65: WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Environment

• Product Certifications: UL
• Ambient Air Temperature For Operation: -10-50 °C
• Signalling Type: 43 tones siren
• Ambient Air Temperature For Storage: -35-70 °C
• Overvoltage Category: class II EN/IEC 61140
• Standards: EN 61000-6-3 || EN 60947-5-1 || EN 60947-01 || EN 61000-6-2
• Noise Level: 0-105 dB continuous or intermittent tone)1 m
• [Us] Rated Supply Voltage: 240 V AC
• Protective Treatment: TC
• Ip Degree Of Protection: IP53 conforming to EN/IEC 60529
