Multi9 - shunt trip release with OC contact - MX + OF - 48 V AC - 48 V DC

• [Uc] Control Circuit Voltage: 48 V AC 50/60 Hz || 48 V DC
• 9 Mm Pitches: 2
• Product Or Component Type: shunt trip release with OC contact
• Range: Multi9
• Signal Contacts Composition: 1 C/O
• [Ie] Rated Operational Current: 6 A <= 240 V AC
• Device Short Name: MX + OF

Complementary

• Height: 82.5 mm
• Mounting Support: DIN rail
• Range Compatibility: Multi9 (Multi9 C60) C60BP || Multi9 (Multi9 C60) C60BPR || Multi9 (Multi9 C60) C60SP || Multi9 (Multi9 GFP) GFP || Multi9 (Multi9 C60H-DC) C60H-DC
• Net Weight: 0.065 kg
• Wire Stripping Length: 9 mm bottom
• Connections - Terminals: clamp terminal bottom) - 1 2.5-2.5 mm² AWG 14) - rigid || clamp terminal bottom) - 2 1.5-1.5 mm² AWG 16) - rigid
• Mounting Mode: fixed
• Local Signalling: action indicator
• Width: 18 mm
• Depth: 68 mm
• Tightening Torque: 1-1 N.m bottom

Offer Sustainability

• Rohs Exemption Information: Yes
• Mercury Free: Yes
• Environmental Disclosure: ENVPEP1305024
• Sustainable Offer Status: Green Premium product
• Toxic Heavy Metal Free: Yes
• Reach Regulation: Free of Substances of Very High Concern above the threshold
• Reach Free Of Svhc: Yes
• China Rohs Regulation: Pro-active China RoHS declaration (out of China RoHS legal scope)
• Eu Rohs Directive: Compliant

Environment

• Product Certifications: PCT || CCC || UL || UR || CSA
• Ambient Air Temperature For Operation: -25-50 °C
• Standards: EN/IEC 60947-1
• Pollution Degree: 3
• Ambient Air Temperature For Storage: -40-85 °C
